RadioInspector Software

The RadioInspector software is a set of applications for searching, monitoring, controlling, analyzing signals in the radio frequency spectrum and localizing their sources. It can be used to provide an efficient and high-speed process of instrumental control of the radio frequency spectrum, search for sources of radio signals, perform metrological measurements of radiation parameters, and perform a number of other applied tasks of radio control and radio monitoring.

Managing open source software

Free software analysis and processing

Free software for WiFi network analysis

Purpose of RadioInspector programs

RadioInspectorRT

The name of the program	Purpose
RadioInspectorRT	Long-term monitoring of the frequency range, including the collection and storage of data on the state of the radio frequency spectrum. A special version of RadioInspectorRC that does not require I_MasterDevice
	RadioInspectorRT program options
DTest option	Digital signal processing and analysis. APCO-P25, DMR,TETRA, DECT, Bluetooth, 802.15.4(ZigBee etc.), 2G(GSM), 3G(UMTS), 4G(LTE), Analog TV(PALL/SECAM/NTSC), DVB -T2. Demodulation (before receiving voice traffic) - APCO-P25, TETRA, DMR, FM, AM. TV signal reception: Analog TV:Pal/Secam/NTSC. Digital TV: DVB-T2. For Cassandra - Cassandra-K, Cassandra-S, Cassandra-SO, Cassandra-T, Cassandra-TM. R&S FSU, R&S ESU, R&S FSL, R&S EPL, R&S PR100, R&S EM100, R&S FSV, R&S FSQ, R&S FSW, R&S ESMD, R&S FSP. Signal Hound USB-SA44B, Signal Hound USB-SA124B, Signal Hound BB60A, Signal Hound BB60C, Signal Hound SM200A. Anritsu MS27102A. Tektronix SA306B. NARDA NRA3000(6000), NARDA IDA3106. FSU FSL FSQ FSW FSV ETL do not support APCO25 and DMR voice demodulation and analog TV video stream. *PR100, EM100 do not support analog TV video stream demodulation (only identify and classify analog TV), DECT and Bluetooth demodulation. (!) Restrictions on the types of demodulators that work depend on the bandwidth of the IQ data and the availability of streaming IQ in the model being used.
Option RT2	– the program is created to work with two types of measuring instruments agreed with the Customer
Option RT3	– the program is created to work with three types of measuring instruments agreed with the Customer
RT-Geo option	Geoinformation system support
RT-RemoteMD option	Remote control of devices via a computer network. To work, you need to purchase I_MasterDevice
RT-SoundScanner option	Control of the second device - (scanning receiver) as a means of audio monitoring without stopping the scanning by the main device (tuning to the frequency, listening and recording the demodulated audio signal without stopping the scanning)

RadioInspectorRC

The name of the program	Purpose
RadioInspectorRC	Long-term monitoring of the frequency range, including the collection and storage of data on the state of the radio frequency spectrum
	RadioInspectorRC program options
DTest option	Digital signal processing and analysis. APCO-P25, DMR,TETRA, DECT, Bluetooth, 802.15.4(ZigBee etc.), 2G(GSM), 3G(UMTS), 4G(LTE), Analog TV(PALL/SECAM/NTSC), DVB -T2. Demodulation (before receiving voice traffic) - APCO-P25, TETRA, DMR, FM, AM. TV signal reception: Analog TV:Pal/Secam/NTSC. Digital TV: DVB-T2. For Cassandra - Cassandra-K, Cassandra-S, Cassandra-SO, Cassandra-T, Cassandra-TM. R&S FSU, R&S ESU, R&S FSL, R&S EPL, R&S PR100, R&S EM100, R&S FSV, R&S FSQ, R&S FSW, R&S ESMD, R&S FSP. Signal Hound USB-SA44B, Signal Hound USB-SA124B, Signal Hound BB60A, Signal Hound BB60C, Signal Hound SM200A. Anritsu MS27102A. Tektronix SA306B. NARDA NRA3000(6000), NARDA IDA3106. FSU FSL FSQ FSW FSV ETL do not support APCO25 and DMR voice demodulation and analog TV video stream. *PR100, EM100 do not support analog TV video stream demodulation (only identify and classify analog TV), DECT and Bluetooth demodulation. (!) Restrictions on the types of demodulators that work depend on the bandwidth of the IQ data and the availability of streaming IQ in the model being used.
Option RC-AN (AN-Analyzer)	Direct instrument control from software, technical analysis of individual emissions
RC-Meas option (Meas - Measurement)	Perform measurements of technical parameters of emissions - (frequency, occupied bandwidth, field strength, etc. This option works only with the option RC-AN
RC-Geo option	Geoinformation system support
RC-RemoteMD option	Remote control of devices over a computer network
RC-SoundScanner option	Control of the second device - (scanning receiver) as a means of audio monitoring without stopping the scanning by the main device (tuning to the frequency, listening and recording the demodulated audio signal without stopping the scanning)
RC-Scanner option	Using scanning receivers to scan the radio (instead of spectrum analyzers)
RC-DB option	Support for a database of measurement results, a database of measuring instruments, a database of standards 17..,19.., a database of employees. Possibility of authorization at the entrance to the program and in the process of work. Note. The database of frequency assignments is always supported and does not depend on the presence of this option.

I_MasterDevice

The name of the program	Purpose
I_MasterDevice	Management of measuring instruments, navigation equipment
	Note. The program comes with the ability to control only one type of measuring instruments agreed with the Customer (spectrum analyzer or measuring receiver).
	I_MasterDevice program options
MD-Geo option	Geoinformation system support
Option MD2	– the program is created to work with two types of measuring instruments agreed with the Customer
MD3 option	– the program is created to work with three types of measuring instruments agreed with the Customer

RadioInspectorRT-Light

The name of the program	Purpose
RadioInspectorRT-Light	Long-term control of the frequency range(s), collection, storage and display of data on the state of the radio frequency spectrum for the entire measurement time (spectrogram or 'waterfall' without restrictions on the size of measurement data) *(not supplied without options)
	RadioInspectorRT-Light program options
Light-SList	Use of frequency assignment database, threshold line, list of signals exceeding the threshold line
Light sound	Recording and analysis of a demodulated audio signal, generating a task for recording a demodulated audio signal when the threshold line is exceeded
Light-Sound Scanner	Controlling a second scanning receiver as an audio monitor without stopping the main receiver from scanning (tuning to a frequency, listening and recording demodulated audio without stopping scanning)
Light-RemoteMD	Ability to control the scanning receiver over the network, transmission of the demodulated audio signal over the network in real time. * To control the receiver with the RadioInspectorRT-Light program (with the Light-RemoteMD option) connected to a remote computer and receive a demodulated audio signal from the receiver over the network in real time, the MasterDevice-Light program with the Light-RemoteMD option connected must be running on the remote computer
MasterDevice Light	Program for managing scanning receivers on a remote computer. Works in the background without displaying working windows. To control the receiver with the RadioInspectorRT-Light program (with the Light-RemoteMD option) connected to a remote computer and receive a demodulated audio signal from the receiver over the network in real time, the MasterDevice-Light program with the Light-RemoteMD option connected must be running on the remote computer

RadioInspectorRP

The name of the program	Purpose
RadioInspectorRP	Post-processing of measurement results stored in the panorama database
	RadioInspectorRP program options
RP-Geo option	Geoinformation system support
Option RP-DB	Support for a database of measurement results, a database of measuring instruments, a database of standards 17..,19.., a database of employees. Possibility of authorization at the entrance to the program and in the process of work. Note. The database of frequency assignments is always supported and does not depend on the availability of this option.

IQ_ProcessPRO

The name of the program	Purpose
IQ_ProcessPRO_DTest_Demod	Digital signal processing and analysis: APCO-P25, DMR,TETRA, DECT, Bluetooth, 802.15.4(ZigBee, etc.), 2G(GSM), 3G(UMTS), 4G(LTE), analog TV, vector analysis (PALL/SECAM/NTSC), DVB-T2. Demodulation (before receiving voice traffic) - APCO-P25, TETRA, DMR, FM, AM. TV signal reception: Analog TV: Pal/Secam/NTSC. Digital TV: DVB-T2

RadioInspectorWiFi and RadioInspectorWiFi-Geo

The name of the program	Purpose
RadioInspectorWIFI	For monitoring devices of Wi-Fi networks in the 2.4/5 GHz bands with the possibility of autonomous, round-the-clock collection of information with further transmission of the accumulated information over the LAN network. Real time operation
RadioInspectorWIFI-Geo	For monitoring devices of Wi-Fi networks in the 2.4/5 GHz bands with the possibility of autonomous, round-the-clock collection of information with further transmission of the accumulated information over the LAN network. Measurements are tied to geographic coordinates. Work in real time. Displaying results on an electronic map

Receiver models working with RadioInspector

Manufacturer	Model
AOR	SR2000A
	AR5001D
Shenzhen Haochen Electronics Technology	AV4051A, AV4051B, AV4051C, AV4051D, AV4051E, AV4051F, AV4051G, AV4051H
Advantest	Advantest R3271, Advantest R3272, Advantest U3772
Aeroflex	Aeroflex 3251, Aeroflex 3252, Aeroflex 3253, Aeroflex 3254
Agilent	Agilent E4411-E4407
	Agilent E4440
Anritsu	Anritsu MS27102A
	Anritsu MS2711E, Anritsu MS2712E, Anritsu MS2713E, Anritsu MS2721A, Anritsu MS2722C, Anritsu MS2723C, Anritsu MS2724C, Anritsu MS2725C, Anritsu MS2726C
	Anritsu MS8911B
HP	HP 8560E-8565E
	HP 8590
ICOM	ICOM PCR1000
	ICOM PCR1500
IFR	IFR 2394, IFR 2395, IFR 2397, IFR 2399
KEYSIGHT	KEYSIGHT N6841A
	KEYSIGHT N9000(13.6GHz), KEYSIGHT N9000(26.5GHz), KEYSIGHT N9000(3GHz), KEYSIGHT N9000(7.5GHz)
	KEYSIGHT N9010
	KEYSIGHT N9020(13.6GHz), KEYSIGHT N9020(26.5GHz), KEYSIGHT N9020(3.6GHz), KEYSIGHT N9020(8.4GHz)
	KEYSIGHT N9030
	KEYSIGHT N9320
	KEYSIGHT N9340
	KEYSIGHT N9342C
	KEYSIGHT N9343C
	KEYSIGHT N9344C
	KEYSIGHT N9912A-104, KEYSIGHT N9912A-106
	KEYSIGHT N9913A, KEYSIGHT N9914A, KEYSIGHT N9915A, KEYSIGHT N9916A, KEYSIGHT N9917A, KEYSIGHT N9918A, KEYSIGHT N9935A, KEYSIGHT N9951A, KEYSIGHT N9952A, KEYSIGHT N9960A, KEYSIGHT N9961A, KEYSIGHT N9962A
LG	LG SA-930
NARDA	NARDA NRA IDA3106, NRA3000, NRA6000
NS	NS 132
	NS 265
	NS 30
R&S	R&S EB200 D-Scan
	R&S EB500
	R&S EM100 3.5GHz, R&S EM100 7.5GHz, R&S EM100+HF907
	R&S ESCI
	R&S ESIB (40)
	R&S ESMD
	R&S ESPI3, R&S ESPI7
	R&S ESU series
	R&S ETL
	R&S FS300
	R&S FSC series
	R&S FSH3, R&S FSH6, R&S FSH18
	R&S FSH4, R&S FSH8, R&S FSH20
	R&S FSL18, R&S FSL3, R&S FSL6
	R&S FSP13, R&S FSP3, R&S FSP30, R&S FSP31, R&S FSP40, R&S FSP7
	R&S FSQ26, R&S FSQ3, R&S FSQ40, R&S FSQ8
	R&S FSU series
	R&S FSV_X series
	R&S FSV3004, R&S FSV3007, R&S FSV3013, R&S FSV3030, R&S FSV3044
	R&S FSW13, R&S FSW26, R&S FSW43, R&S FSW50, R&S FSW67, R&S FSW8, R&S FSW85, R&S PR100
	R&S PR100+HF907
	R&S PR200
signal hound	Signal Hound SM200A api 1.xx
	Signal Hound SM200A api 2.xx
	Signal Hound SM200B
	SignalHound BB60A
	SignalHound BB60C API 2.xx
	SignalHound BB60C api 4.xx
	SignalHound USB-SA124A
	SignalHound USB-SA124B
	SignalHound USB-SA44B
Tektronix	Tektronix H600
	Tektronix RSA306B
	Tektronix RSA503A, Tektronix RSA507A, Tektronix RSA513A, Tektronix RSA518A, Tektronix RSA603A, Tektronix RSA607A,
USG	USG-30A, USG-9A
USRP	USRP B200
	USRP B210
WillTek	WillTek 9101
WinRadio	WinRadio 305

Receiver models working with RadioInspectorRT-Light

Manufacturer	Model
AOR	SR2000 SR2000A AR8000 AR8200 AR8200-MK2 AR8200-MK3 AR8600 AR8600-MK2 AR3000 AR3000A AR5000 AR5000+3 AR5000A AR5000A+3 . AR5001D. AR-DV1, AOR-ALPHA
ICOM	IC-R10, IC-R20, PCR-100, PCR-1000, PCR-1500, PCR2500, IC-R8500, IC-R9500
R&S	EB200
